Configuring IPFIX receivers
Configuring ipfix receivers via the .env file
/var/qoestor/backend/.env
The standard configuration looks like this
#Ipfix form DPI 0 IPFIX_FULLFLOW_PORT_TYPE[0]=tcp IPFIX_FULLFLOW_PORT[0]=1500 #IPFIX_FULLFLOW_ROTATE_MINUTES[0]=10 #IPFIX_FULLFLOW_ROTATE_DELAY_SECONDS[0]=0 #IPFIX_FULLFLOW_FW_MAX_QUEUE_SIZE[0]=10 #IPFIX_FULLFLOW_DUMP_INSERT_PROCESSES[0]=0 #IPFIX_FULLFLOW_EXPORT[0]=10.0.0.2/9920/tcp,10.0.0.3/3440/udp IPFIX_CLICKSTREAM_PORT_TYPE[0]=tcp IPFIX_CLICKSTREAM_PORT[0]=1501 #IPFIX_CLICKSTREAM_ROTATE_MINUTES[0]=12 #IPFIX_CLICKSTREAM_ROTATE_DELAY_SECONDS[0]=400 #IPFIX_CLICKSTREAM_FW_MAX_QUEUE_SIZE[0]=10 #IPFIX_CLICKSTREAM_DUMP_INSERT_PROCESSES[0]=0 #IPFIX_CLICKSTREAM_EXPORT[0]=10.0.0.2/9921/tcp,10.0.0.3/3441/udp IPFIX_GTPFLOW_PORT_TYPE[0]=tcp IPFIX_GTPFLOW_PORT[0]=1502 #IPFIX_GTPFLOW_ROTATE_MINUTES[0]=10 #IPFIX_GTPFLOW_ROTATE_DELAY_SECONDS[0]=0 #IPFIX_GTPFLOW_FW_MAX_QUEUE_SIZE[0]=10 #IPFIX_GTPFLOW_DUMP_INSERT_PROCESSES[0]=0 #IPFIX_GTPFLOW_EXPORT[0]=10.0.0.2/9921/tcp,10.0.0.3/3441/udp IPFIX_NATFLOW_PORT_TYPE[0]=tcp IPFIX_NATFLOW_PORT[0]=1503 #IPFIX_NATFLOW_ROTATE_MINUTES[0]=10 #IPFIX_NATFLOW_ROTATE_DELAY_SECONDS[0]=0 #IPFIX_NATFLOW_FW_MAX_QUEUE_SIZE[0]=10 #IPFIX_NATFLOW_DUMP_INSERT_PROCESSES[0]=0 #IPFIX_NATFLOW_EXPORT[0]=10.0.0.2/9921/tcp,10.0.0.3/3441/udp IPFIX_DNSFLOW_PORT_TYPE[0]=tcp IPFIX_DNSFLOW_PORT[0]=1504 #IPFIX_DNSFLOW_ROTATE_MINUTES[0]=10 #IPFIX_DNSFLOW_ROTATE_DELAY_SECONDS[0]=0 #IPFIX_DNSFLOW_FW_MAX_QUEUE_SIZE[0]=10 #IPFIX_DNSFLOW_DUMP_INSERT_PROCESSES[0]=0 #IPFIX_DNSFLOW_DPI_ID[0]=30 #IPFIX_DNSFLOW_BALANCER_SUB_PROTO[0]=tcp #Traffic direction definition # 0 - as is # 1 - by AS (for fullflow only) # 2 - by CIDR (for fullflow and clickstream) # 3 - by both: AS and CIDR # 4 - any: AS or CIDR TRAFFIC_DIR_DEF_MODE=0 #Subscriber filter # 0 - no filter # 1 - by AS (for fullflow only) # 2 - by CIDR (for fullflow and clickstream) # 3 - by both: AS and CIDR # 4 - any: AS or CIDR SUBSCRIBER_FILTER_MODE=0 #Subscriber exclude # 0 - no exclude # 1 - by AS (for fullflow only) # 2 - by CIDR (for fullflow and clickstream) # 3 - by both: AS and CIDR # 4 - any: AS or CIDR SUBSCRIBER_EXCLUDE_MODE=0 #Enable host (url) categories dics autoload URLS_CATEGORIES_DIC_AUTOLOAD_ENABLED=1 #Enable asnum dic autoload ASNUM_DIC_AUTOLOAD_ENABLED=1 #Enable auto replacing Login with vchannel on insert # 0 - Disabled # 1 - Enabled # 2 - Enabled if Login is empty ULR_REPLACE_LOGIN_WITH_VCHANNEL=0 # Use dictionary when replacing login ULR_USE_DIC_WHEN_REPLACING_LOGIN=0 # Enable autoload of vchannel_name_dic ULR_VCHANNEL_NAME_DIC_AUTOLOAD_ENABLED=0 # vchannel_name_dic remote url ULR_VCHANNEL_NAME_DIC_URL= #Import NAT events from fullflow NAT_IMPORT_FROM_FULLFLOW # 0 - Disabled # 1 - Enabled #Fields to save when aggregating NAT log (bitmask) # 0x1 - Save protocol ID # 0x2 - Save event type, # 0x4 - Save source ipv4, # 0x8 - Save source port, # 0x10 - Save destination ipv4, # 0x20 - Save destination port, # 0x40 - Save post NAT source ipv4, # 0x80 - Save post NAT source_port, # 0x100 - Save session ID, # 0x200 - Save login, # 0x400 - Save DPI ID NAT_AGG_LOG_FIELDS_TO_SAVE_BITMASK=0 #Time interval for aggregating NAT logs NAT_AGG_LOG_GROUP_TIME_INTERVAL # 1 - 1 minute # 5 - 5 minutes # 10 - 10 minutes # 15 - 15 minutes # 30 - 30 minutes # 60 - 60 minutes
In the presented configuration, the launch of fullflow and clickstream receivers is configured on tcp sockets 1500 and 1501, respectively. «0» in the array index means that reception is coming from DPI 0.
It is better to use tcp, because for udp packets can be lost when the MTU is exceeded.
Parameter list
- IPFIX_FULLFLOW_PORT_TYPE[i] и IPFIX_CLICKSTREAM_PORT_TYPE[i] determine the type of traffic received on the port: tcp or udp. It is recommended to install tcp.
- IPFIX_FULLFLOW_PORT[i] и IPFIX_CLICKSTREAM_PORT[i] determine the port number.
- TRAFFIC_DIR_DEF_MODE и SUBSCRIBER_FILTER_MODE defines the subscriber filtering mode according to the asnum_local_dic and subnets_local_dic directories. TRAFFIC_DIR_DEF_MODE = 0 and SUBSCRIBER_FILTER_MODE = 0 mean that there is no need to calculate traffic direction and filter subscribers.
- SUBSCRIBER_EXCLUDE_MODE defines the subscriber filtering mode according to the asnum_exclude_diс and subnets_exclude_dic directories. SUBSCRIBER_EXCLUDE_MODE = 0 means no filtering is required.
- IPFIX_FULLFLOW_EXPORT[i] and IPFIX_CLICKSTREAM_EXPORT[i] make it possible to configure export to third-party receivers. Format ip/port/proto[,ip/port/proto].
- IPFIX_FULLFLOW_ROTATE_MINUTES[i] и IPFIX_CLICKSTREAM_ROTATE_MINUTES[i] make it possible to configure the period of rotation of dumps and write them to the database. By default, this is 10 minutes for fullflow and 12 minutes for clickstream.
- IPFIX_FULLFLOW_ROTATE_DELAY_SECONDS[i] и IPFIX_CLICKSTREAM_ROTATE_DELAY_SECONDS[i] make it possible to configure the delay for inserting data for a certain number of seconds. The default for fullflow is 0 seconds, for clickstream it is 400 seconds. The latency for clickstream relative to fullflow is needed to ensure that the fullflow and clickstream logs are connected to enrich statistical reports.
- IPFIX_FULLFLOW_FW_MAX_QUEUE_SIZE[i] и IPFIX_CLICKSTREAM_FW_MAX_QUEUE_SIZE[i] determine the maximum queue size on receivers. Better not to touch.
If the configuration has changed, you need to run
fastor-restart
The following configuration example allows you to configure reception from multiple DPI
#Ipfix form DPI 0 IPFIX_FULLFLOW_PORT_TYPE[0]=tcp IPFIX_FULLFLOW_PORT[0]=1500 IPFIX_CLICKSTREAM_PORT_TYPE[0]=tcp IPFIX_CLICKSTREAM_PORT[0]=1501 #Ipfix form DPI 1 IPFIX_FULLFLOW_PORT_TYPE[1]=tcp IPFIX_FULLFLOW_PORT[1]=1510 IPFIX_CLICKSTREAM_PORT_TYPE[1]=tcp IPFIX_CLICKSTREAM_PORT[1]=1511 #Ipfix form DPI 2 IPFIX_FULLFLOW_PORT_TYPE[2]=tcp IPFIX_FULLFLOW_PORT[2]=1520 IPFIX_CLICKSTREAM_PORT_TYPE[2]=tcp IPFIX_CLICKSTREAM_PORT[2]=1521
An example of a configuration when subscriber identification by CIDR is required
This configuration is relevant in cases when the DPI is installed on the mirror.
TRAFFIC_DIR_DEF_MODE=2 SUBSCRIBER_FILTER_MODE=2
Don't forget to set up the subnets_local_dic reference for this configuration example!
Configuration example when export to third-party receivers is configured
IPFIX_FULLFLOW_PORT_TYPE[0]=tcp IPFIX_FULLFLOW_PORT[0]=1500 IPFIX_FULLFLOW_EXPORT[0]=10.0.0.2/1600/tcp IPFIX_CLICKSTREAM_PORT_TYPE[0]=tcp IPFIX_CLICKSTREAM_PORT[0]=1501 IPFIX_CLICKSTREAM_EXPORT[0]=10.0.0.2/1601/tcp
Restarting receivers
Restarting all receivers can be done with the command
fastor-restart
If you need to restart the receivers separately, this can be done by restarting the services, for example
- For CentOS 7
systemctl restart qoestor_fullflow_0.service systemctl restart qoestor_clickstream_0.service
- For CentOS 6
service qoestor_fullflow_0 stop service qoestor_clickstream_0 stop service qoestor_fullflow_0 start service qoestor_clickstream_0 start
Stopping receivers
- For CentOS 7
systemctl stop qoestor_fullflow_0.service systemctl stop qoestor_clickstream_0.service
- For CentOS 6
service qoestor_clickstream_0 stop service qoestor_fullflow_0 stop
Stopping and starting the clickhouse database
- Stopping
fastor-db-stop
- Starting
fastor-db-restart
